• M55 Air Wire Rope Hoist – Pneumatic

M55: Air Wire Rope Hoist-Pneumatic Hoist

SUMMARY OF FEATURES

  • Moderate service (H3) hoist
  • Accessible in-line gear train
  • Mechanical load brake
  • Rotary vane air motor
  • Emergency upper limit switch
  • Single-reeved

Download the M55: Air Hoist Product Sheet

GET A FREE HOIST QUOTE NOW
Category:

Description

Load Capacity (lbs.)
Air Hoist Model Number
Lift Height (ft.)
Lift Speed (ft./min.)
1,000
10AW
4035
1,000
10AL50
35
1,00010ADL10035
2,000
20AW4016
2,00020AL5016
2,00020ADL10016
4,00040AW208

OPTIONAL FEATURES

  • Manual and motorized trolleys
  • Air motor brake
  • Upper and lower hook position limit switch
  • Single-speed push-button pendant
  • Variable speed lever pendant
  • Spark-resistant features
  • Weather-resistant finishes and components

ADDITIONAL FEATURES

  • Variable speed rope control on lug mounted and push trolley models
  • 4-button single-speed air push-button pendant on motorized trolley units
  • Lug mounted

STANDARD AIR POWERED WIRE ROPE HOISTS

Variable speed pneumatic hoist positions loads accurately without electronics.

Lift loads safely in hazardous environments.

Minimize sparking, static and electrical hazards with this air-powered hoist.

  • Eliminate electric motor dangers by using air motors for both hoist and trolley
  • Lift with confidence in dusty and volatile environments by using spark resistant components:
    • Stainless steel wire rope
    • Bronze bottom block and hook
    • Copper-Beryllium or Micarta trolley wheels
    • Rubber bumpers
  • Operate hoist in remote locations without electrical service

Increase Clearance under Hoist without increasing crane height!

Air wire rope hoist requires just 16″ of beam-to-hook clearance (headroom).

  • Raise molds and tooling further from production machinery during changeovers
  • Maximize overhead clearance as products are positioned in paint and spray booths
  • Extend clearance under baskets when lifting over dip tanks side walls
  • Minimize motor and pump service crane heights

Raise and Lower loads with Precision!

Variable speed operation is affordable with pneumatic controls.

  • Slowly lower assemblies and mold sections into place with variable speed rope controls
  • Position loads from a distance and gradually start trolleys with variable speed lever pendants
  • Adjust the lift speed as required without being limited to one or two preset speeds
GET A FREE AIR HOIST QUOTE NOW

All products are available in Stainless Steel and Made in the U.S.A.
